Aluminum profiles play a crucial role in various industrial applications due to their lightweight, durability, and excellent conductivity. If you are looking for reliable options, understanding the choices available from Indonesia extruded aluminum manufactures can help optimize your projects.
Among many, the five Exalummetal industrial aluminum products stand out for their versatility and efficiency in the manufacturing and construction sectors. These profiles can reduce handling costs but also cut down maintenance and machining time, making them smart investments for regular procurement. Let’s explore these five common aluminum extrusion profiles offered by a reputable Indonesia manufacturer.
Flat Bar
The flat bar profile is a versatile component that serves multiple departments simultaneously. It can be transformed into brackets, base plates, stiffeners, or busbar stock with minimal processing. This profile is listed with specific section numbers for easy reordering, ensuring consistent dimension and quality.
For instance, section 10031 measures 25.00 x 3.00 mm with a lightweight 0.203 kg per meter, making it ideal for light-duty tasks. Meanwhile, there are also section 10204 offers a broader strip of 120.00 x 8.00 mm with a 2 mm radius, weighing 2.592 kg per meter that more suitable for replacing fabricated plates.
Spandrel
Spandrel profiles are essential in curtain wall systems, where they cover the blind bands between glazing runs. Their main function is to conceal slab edges, ducting, and insulation for a seamless facade appearance. These profiles are particularly useful in large projects such as towers, which can absorb several tonnes of aluminum.
Profile 98108 spans 82.70 mm with a 10.30 mm depth, a 1.00 mm wall thickness, and weighs 0.520 kg per meter, designed for exposed positions where strength is important. Another variant, profile 62020, measures 97.00 mm with a 9.30 mm return and is lighter at 0.260 kg per meter. T
Equal Angle
Equal angle profiles create two legs of identical width joined at a 90-degree angle, commonly used for bracing, corner reinforcement, and panel edging. Their frequent use in many projects makes them a smart profile to keep regularly stocked.
Among sixteen variants, type 20026 offers a trim design of 12.70 x 0.85 mm at 0.056 kg per meter, suitable for light framing tasks. Mid-range type 20047 measures 19.00 x 1.00 mm and weighs 0.100 kg per meter, providing sufficient rigidity for enclosure framing without adding excessive weight.
C Channel
C Channel or unequal channel profiles have a U shape with differing flange and web dimensions. These variations reduce the need for folding or welding when securing panel edges, improving assembly speed and finish.
Five types of this profile are available, with variant 32052 measuring 38.10 x 25.40 mm and a 0.90 mm wall thickness. Weighing 0.212 kg per meter, it is popular for skirting and board retention. A larger variant, 32053, spans 101.60 x 19.05 mm with a weight of 0.336 kg per meter, allowing for finishing a full sheet edge in a single continuous piece.
Heat Sink
Heat sink extrusions focus on thermal management by increasing the surface area exposed to air. Their fin design helps remove heat from electronic components like drives, converters, and lighting systems.
Code 96003 is a tall heat sink measuring 50.00 x 60.00 mm with 1.50 mm fins, weighing 0.875 kg per meter. It provides an impressive 446.256 mm of perimeter surface, delivering effective cooling for high-load applications. On the other hand, code 96008 is a compact option sized 23.40 x 17.00 mm at 0.331 kg per meter, suitable for smaller controllers and drives.
These five aluminum extrusion profiles combine frequent industrial applications with practical dimensions and qualities. Sourced from a qualified Indonesian billet and available in mill finish, anodized, or powder-coated forms, these profiles form the backbone of many efficient and clean industrial builds.
Place Your Order With Our Indonesia Extrusion Factory
Take advantage of consistently high-quality production and reliable delivery from an expert Indonesia aluminum extrusion manufacturer. If you want to streamline ordering, simply send the section number, cut length, quantity in kilograms or pieces, and the finishing required to inquiry@exalummetal.com or reach out via WhatsApp at +62 811 9429 970. The factory ships internationally to markets such as the United States, United Kingdom, Australia, and Canada. For custom profiles not yet cataloged, new dies can be opened to meet specific requirements.
